Function
code
Name
Detailed parameter description
Default
value
Modi
fy
will be displayed.
P12.30
System inertia of
motor 2
0–30.000kgm
2
0.000
○
P12.31–
P12.32
Reserved
variables
0–65535
0
○
P13 group Control parameters of synchronous motor
P13.00
Reduction rate of
the injection
current of
synchronous
motor
0.0%–100.0% rated motor current
80.0%
○
P13.01
Initial pole
detection mode
0: Pull-in current
1: High-frequency superposition (reserved)
2: Pulse superposition (reserved)
0
◎
P13.02
Pull-in current 1
Pull-in current is the pole position orientation current;
pull-in current 1 is valid within the lower limit of pull-in
current switch-over frequency threshold. If users
need to increase the starting torque, increase the
value of this function code properly.
Setting range: 0.0%–100.0% (rated motor current)
20.0%
○
P13.03
Pull-in current 2
Pull-in current is the pole position orientation current;
pull-in current 2 is valid within the upper limit of
pull-in current switch-over frequency threshold, and
users do not need to change pull-in current 2 under
common situations.
Setting range: 0.0%–100.0% (rated motor current)
10.0%
○
P13.04
Switch-over
frequency of
pull-in current
0.00Hz–P00.03 (max. output frequency)
10.00Hz
○
P13.05
High-frequency
superposition
frequency
(reserved)
200Hz–1000Hz
500Hz
◎
P13.06
High-frequency
superposition
voltage
0.0–300.0% rated motor voltage
100.0%
◎
P13.07
Reserved
variables
0–400.0
0.0
○
