INVT Goodrive350 Series

Goodrive350 series high-performance multi-function inverter Chapter 6
-185-
Function
code
Name
Detailed parameter description
Default
value
Modi
fy
P13.08
Control
parameter 1
0–0xFFFF
0
○
P13.09
Control
parameter 2
0–655.35
2.00
○
P13.10
Reserved
variables
0–359.9
0
○
P13.11
Maladjustment
detection time
This parameter is used to adjust the responsiveness
of anti-maladjustment function. If the load inertia is
large, increase the value of this parameter properly,
however, the responsiveness may slow down
accordingly.
Setting range: 0.0–10.0s
0.5s
○
P13.12
High-frequency
compensation
coefficient of
synchronous
motor
This parameter is valid when the motor speed
exceeds the rated speed. If motor oscillation
occurred, adjust this parameter properly.
Setting range: 0.0–100.0%
0.0
○
P13.13–
P13.19
Reserved
variables
0–65535
0
○
P14 group Serial communication function
P14.00
Local
communication
address
Setting range: 1–247
When the master is writing frames, and the slave
communication address is set to 0, it is the broadcast
communication address, and all the slaves on the
MODBUS bus will accept this frame, but the slave
never responds.
Local communication address is unique in the
communication network, which is the basis for
point-to-point communication between the upper
computer and the inverter.
Note: The slave address cannot be set to 0.
1
○
P14.01
Communication
baud rate setup
This parameter is used to set the data transmission
speed between upper computer and the inverter.
0: 1200BPS
1: 2400BPS
2: 4800BPS
3: 9600BPS
4: 19200BPS
4
○
