INVT Goodrive350 Series

Goodrive350 series high-performance multi-function inverter Chapter 6
-213-
Function
code
Name
Detailed parameter description
Default
value
Modi
fy
P25.15
S6 switch-off
delay
0.000s
○
P25.16
S7 terminal
switch-on delay
0.000s
○
P25.17
S7 switch-off
delay
0.000s
○
P25.18
S8 terminal
switch-on delay
0.000s
○
P25.19
S8 switch-off
delay
0.000s
○
P25.20
S9 terminal
switch-on delay
0.000s
○
P25.21
S9 switch-off
delay
0.000s
○
P25.22
S10 terminal
switch-on delay
0.000s
○
P25.23
S10 switch-off
delay
0.000s
○
P25.24
Lower limit value
of AI3
These function codes define the relation between
analog input voltage and corresponding set value of
analog input. When the analog input voltage
exceeds the range of max./min. input, the max. input
or min. input will be adopted during calculation.
When analog input is current input, 0–20mA current
corresponds to 0–10V voltage.
In different application cases, 100% of the analog
setting corresponds to different nominal values.
The figure below illustrates several settings.
-100%
100%
Corresponding
setting
AI
10V
20mA
0
AI3/AI4
Input filter time: Adjust the sensitivity of analog input,
increase this value properly can enhance the
0.00V
○
P25.25
Corresponding
setting of lower
limit of AI3
0.0%
○
P25.26
Upper limit value
of AI3
10.00V
○
P25.27
Corresponding
setting of upper
limit of AI3
100.0%
○
P25.28
Input filter time of
AI3
0.030s
○
P25.29
Lower limit value
of AI4
0.00V
○
P25.30
Corresponding
setting of lower
limit of AI4
0.0%
○
P25.31
Upper limit value
of AI4
10.00V
○
P25.32
Corresponding
100.0%
○
