INVT Goodrive350 Series

Goodrive350 series high-performance multi-function inverter Chapter 5
-65-
Function
code
Name
Detailed parameter description
Default
value
6: MODBUS communication (the same as
above)
7: PROFIBUS /CANopen/ DeviceNet
communication (the same as above)
8: Ethernet communication (the same as above)
9: Pulse frequency HDIB (the same as above)
10: EtherCat/Profinet communication
11: PLC
12: Reserved
Note: Source 1-11, 100% relative to the max.
frequency
P03.15
Source of upper
limit frequency
setup of reverse
rotation in torque
control
0: Keypad (P03.17)
1: AI1 (100% corresponds to max. frequency)
2: AI2 (the same as above)
3: AI3 (the same as above)
4: Pulse frequency HDIA (the same as above)
5: Multi-step (the same as above)
6: MODBUS communication (the same as
above)
7: PROFIBUS /CANopen/ DeviceNet
communication (the same as above)
8: Ethernet communication (the same as above)
9: Pulse frequency HDIB (the same as above)
10: EtherCat/Profinet communication
11: PLC
12: Reserved
Note: Source 1-11, 100% relative to the max.
frequency
0
P03.16
Keypad limit value
of upper limit
frequency of
forward rotation in
torque control
0.00Hz–P00.03 (max. output frequency)
50.00 Hz
P03.17
Keypad limit value
of upper limit
frequency of
reverse rotation in
torque control
0.00Hz–P00.03 (max. output frequency)
50.00 Hz
P03.18
Source of upper
0: Keypad (P03.20)
0
