INVT SPC Series User Manual

SPC Series Solar Pump Inverter Function parameter list
-41-
Function
code
Name
Description
Default
Modify
voltage and reference voltage to the
reference voltage, which is abs (Actual
voltage – Reference voltage) *
100.0%/(Reference voltage), exceeds
P15.03. The default value is 0.0%.
abs: The absolute value is used.
P15.04
PID output
upper limit
frequency
P15.05–100.0% (100.0% corresponding
to P00.03)
P15.04 is used to limit the max. value of
target frequency.
100.0% corresponds to P00.03.
After PI adjustment, the target frequency
cannot exceed the upper limit.
100.0%
○
P15.05
PID output
lower limit
frequency
0.0%–P15.04 (100.0% corresponding to
P00.03)
P15.05 is used to limit the min. value of
target frequency. 100.0% corresponds to
P00.03.
After PI adjustment, the target frequency
cannot be less than the lower limit.
20.0%
○
P15.06
KP1
0.00–100.00
Proportional coefficient 1 of target
frequency
A greater value indicates stronger effect
and faster adjustment.
5.00
○
P15.07
KI1
0.00–100.00
Integral coefficient 1 of target frequency
A greater value indicates stronger effect
and faster adjustment.
5.00
○
P15.08
KP2
0.00–100.00
Proportional coefficient 2 of target
frequency
A greater value indicates stronger effect
and faster adjustment.
35.00
○
P15.09
KI2
0.00–100.00
Integral coefficient 2 of target frequency
A greater value indicates stronger effect
35.00
○
