ION TIGER User Manual

TIGER Instrument User Manual V3.10
Unrivalled Gas Detection. Page 45 of 72 ionscience.com
Click on a session. Details of the data collected during that session are presented in numerical and
graphical form on the Datalog screen.
Use the menu accessed from the Menu button in the top right-hand corner of the window to zoom,
print, or export the data.
Important: The Delete option on the menu deletes all logged data from your
TIGER. Ensure all valuable data is exported to your PC before selecting it.
Health & Safety Screen
This screen displays the latest Health and Safety readings held on your TIGER, if the relevant upgrade
has been installed. New readings are downloaded from the TIGER when the instrument is read.

ION TIGER Specifications

General

Lamp Energy	10.6 eV
Minimum Resolution	0.001 ppm
Operating Humidity	0 – 99% RH (non-condensing)
Resolution	0.001 ppm
Power Supply	Rechargeable Li-ion battery
Operating Temperature	-20 to 50 °C, -4 to 122 °F (non-hazardous area)
