Taking Snapshots
The first time you “read” an instrument a snapshot is taken automatically (see Snapshots Screen).
On subsequent occasions this pop-up is displayed:
Click Yes or No as required.
To take a snapshot of a connected instrument at any time, click on the IRN of the instrument in the
Instrument(s) list, then click Take Snapshot on the screen that is then displayed.

ION TIGER Specifications

General

Lamp Energy	10.6 eV
Minimum Resolution	0.001 ppm
Operating Humidity	0 – 99% RH (non-condensing)
Resolution	0.001 ppm
Power Supply	Rechargeable Li-ion battery
Operating Temperature	-20 to 50 °C, -4 to 122 °F (non-hazardous area)
