Then ensuring, the PTFE Filter Disc and O-ring are correctly positioned, screw the Sensor Cover back
onto the Instrument Body. Do not over-tighten.
The instrument MUST now be re-calibrated.

ION TIGER Specifications

General

Lamp Energy	10.6 eV
Minimum Resolution	0.001 ppm
Operating Humidity	0 – 99% RH (non-condensing)
Resolution	0.001 ppm
Power Supply	Rechargeable Li-ion battery
Operating Temperature	-20 to 50 °C, -4 to 122 °F (non-hazardous area)
