7 Specifications
General Specifications
Main Supply Voltage 100-240 VAC, 50-60 Hz
Supply Voltage 9 VDC
Current Consumption 1 A max
Operating temperature
0 °C to 40 °C
Physical dimensions 165x64x33.4 (L*W*H [mm])
Standards Full CE
Line Specifications
Line loop current 40 mA max
Line supply voltage
- 48 VDC ± 10%
Line impedance 600 Ohm
Dial tone
400 Hz ± 1%
Ring generator 42 Vrms/25 Hz
Line signaling DTMF
Line Connector (2W
TIP/RING)
RJ11-C (pin 2, 3- TIP, pin 4, 5- RING)
Data Port Specifications
Interface port RS232
Protocol AT Command Compatible
GSM Channel Specifications
Dual band GSM 900/1800Mhz
Standards Type Approval CE mark.
GSM module WaveCOM WISMO 2D
Optional Features
Fax Requires a data connection between the Smartcell
111L and a PC with Winfax version 10 and up.
SMS Requires a data connection between the
Smartcell 111L and a PC running an SMS
application that supports WaveCOM module.
Safety Standards
N
o
QUAEMC_EN.15242C Conforms to the EMS requirements of: EN 301 489-
7 V1.1.1:2000, AS/NZS 3548: 1995 with
Amendments 1 & 2:1997
N
o
QUASAF_EN.15242C Conforms to the Safety requirements of: IEC 60950:
1999, EN 60950: 2000, AS/NZS 60950:2000 and
ACA TS 001:1997 standards
*Specifications are subject to change without notice
