IP Gear SmartCell 111L User Guide
1 Introduction
1.1 Overview
The Smartcell 111L gateway enables direct connection of an organization's
internal telephony system to any commercial cellular network, via an already
existing Private Automatic Branch Exchange (PABX) system.
The Smartcell 111L interfaces with a regular two-wire analogue line interface
and a GSM cellular network to create a cellular gateway. Smartcell 111L
operates via dual band GSM cellular networks (900/1800MHz). A special
version operates at 900/1900MHz.
The functionality of the Smartcell 111L is usually transparent to users when used
with a PABX with LCR (Least Cost Routing) capability. The PABX recognizes
Smartcell 111L as a trunk interface and the routing is done in the PABX itself. In
a PABX with no LCR capability, the user selects the proper trunk for the call. In
this case, the user has to know when to use the trunk with the 111L and when to
use other trunks.
The Smartcell 111L can be used with a plain analog telephone as well. In this
case, every time you go off-hook the 111L will send you a dial tone. You can use
this configuration as a replacement for a fixed line telephone.
The Smartcell 111L can be used to send and receive SMS, fax and data
transmissions (These features are optional; contact your technical support for
further information).
1.2 Packing List
The Smartcell 111L is shipped with the following components:
Smartcell 111L unit
An antenna with a 3-meter long cable.
Power supply (AC adaptor with rated output 9VDC, 1A)
A set of 3 screws
This user manual
Optional items
The following items may be supplied on a separate order
Data cable for fax and SMS
An antenna with a 15-meter long cable.
