1.2 System Components
ITEM
OPTION
BOARD
DESCRIPTION
BKSU
Basic KSU
EKSU
Expansion KSU
PSU
Power Supply Unit (350W)
Main Board MPB100
Main Processor Board 100
DSIU
Digital and Single Line Interface Unit (Default; 6 DKT, 6 SLT)
MODU
Modem Unit (Optional; 33Kbps)
MPB300
Main Processor Board 300
DSIU
Digital and Single Line Interface Unit (Default; 6 DKT, 6 SLT)
MODU Modem Unit (Optional; 33Kbps)
Trunk
Boards
LCOB4
4 LCO Interface Board
CMU4
4 Call Metering Unit (50Hz/12KHz/16KHz)
LCOB8
8 LCO Interface Board
CMU4
4 Call Metering Unit (50Hz/12KHz/16KHz)
LCOB12
12 LCO Interface Board
CMU4 4 Call Metering Unit (50Hz/12KHz/16KHz)
BRIB2
2 So/To Interface Board (4 channels)
BRIB4
4 So/To Interface Board (8 channels)
PRIB
DCO Interface Board (1 PRI or 1 E1R2, 30chs / 1 T1, 24chs)
Extension
Boards
SLIB12
12 SLT Interface Board
SLIB12C
12 SLT Interface Board (RJ21)
SLIB24
24 SLT Interface Board
SLIB24C
24 SLT Interface Board (RJ21)
DTIB12
12 DKT Interface Board
DTIB12C
12 DKT Interface Board (RJ21)
DTIB24
24 DKT Interface Board
DTIB24C
24 DKT Interface Board (RJ21)
Function
Boards
WTIB4
4 Base Wireless Terminal Interface Board
WTIB8
8 Base Wireless Terminal Interface Board
VMIB
Voice Mail Interface Board (8 channels, 100hrs)
AAIB
Auto Attendant Interface Board (8 channels)
VOIB8
8 VoIP Interface Board
VOIB24
24 VoIP Interface Board
ETC GDC-400B
GDC-600B
GDC-600BE
DECT Base Station (6 channels per Base)
WMK
Wall Mount Bracket
