iPECS-MG Quick Start Guide
30
5
S
S
T
T
A
A
R
R
T
T
I
I
N
N
G
G
T
T
H
H
E
E
I
I
P
P
E
E
C
C
S
S
-
-
M
M
G
G
5.1 Before Starting the iPECS-MG System
The first step in starting the newly installed iPECS-MG system is initializing the databases. The following procedure
describes the necessary Steps:
1) Verify MPB100/MPB300 has been inserted into the MPB slot of the first KSU.
- Before programming the System, Switch 1-1 pole should be OFF and then power cycle OFF and ON to
initialize the default System database.
2) Plug the AC power cord into the iPECS-MG System and AC outlet. Turn on the iPECS-MG System; after
installing the 1st, 2nd and 3rd KSUs, Power-On as follows:
- Order of Power-On Procedure: 3
rd
KSU  2
nd
KSU  1
st
KSU.
- After KSU(s) have been turned-On, you have to reset the MPB100/MPB300 in the 1
st
KSU.
3) Once the database has been initialized, switch 1-1 should be placed in the ON position to protect the User
database and to protect the features being programmed in Admin. programming.
4) Switch 1-2 should be placed in the ON position to feed the Lithium Battery Voltage to SRAM/RTC directly
(protects the User Database and System Time/Date information, etc.).
5.2 Basic Programming
The iPECS-MG System can be programmed to meet an individual customer’s needs. There are two ways to perform
Admin Programming:
• Web Admin Programming
• DKT Programming
5.2.1 Web Admin Programming
NOTE
• For complete instructions on using the Web Admin, refer to the iPECS-MG Web Administration
Manual.
Upon entering WEB Admin Programming mode, the default System IP Address is the ’10.10.10.1’. The IP
Address can be changed using PGM108 in Keyset programming or with the IP configuration command in
maintenance mode. Another way is to connect the PC to MPB with LAN cable and configure the PC IP address
to ’10.10.10.xx’, and PC gateway address to ’10.10.10.254’.
