 | Appendix
146
YLS-K
Apart from the buttons Reset
and E-Stop all operating functions in
LaserNet are locked in ROBOT mode. By activating the signal Internal
control enabled (depending on the communication protocol), you can
activate the internal control, i.e. the power preselection and ramping
time function (ramping rise and fall time) in LaserNet.
Message
Laser radiation enabled
Type
Status
Description
This status message indicates that all prerequisites for laser emission
have been met and the laser emission has been switched on (via Laser-
Net or fieldbus). This is the case even when the preselected power is
zero watts (0 W).
The following prerequisites must be met for enabling of the laser radia-
tion:
• There are no laser-related failures.
• The laser power supply is switched on (Laser power supply ON).
• The laser is in the status Laser ready.
Message
External control
Type
Status
Description
This status message is active when the operation option External con-
trol has been enabled.
If this option is used, you can control the start and end of the laser emis-
sion via the XP2 interface (see interface description).
If you have selected the External control in the TEST mode (via Laser-
Net), this remains active even after switching to the ROBOT mode.
Message
Analog control
Type
Status
Description
If the operation option Analog Control is active, this status message ap-
pears (depending on the communication protocol).
If this option is enabled, you can control the laser power via the XP4-
analog interface (see interface description).
Message
Hardwiring active
Type
Status
Description
This status message is active when the control of the laser via the hard-
wiring interface has been enabled.
