To determine OSMO software version, inspect the OSMO date code.

OSMO Date Code

OSMO Date Code

JEN1387Xyymmdd01xxxxxx

JEN1387Xyymmdd02xxxxxx

JEN1387Xyymmdd03

xxxxxx

OSMO Version #

Version 1 (-1707)

Version 2 (-1308)

Version 3 (-1814)

OSMO Download procedure
