Manual No. 0183B 15/29 IPC Series Service Manual
IPC 3kg､6kg Single Display Asia Service Parts List
No. Parts Name Weighing Capacity Q'ty
1 PLATTER 1
2 PLATE: SUPPORT 2
3 LOAD CELL (CZL-6D-C3-5kg-1000) 3kg 1
3 LOAD CELL (CZL-6D-C3-10kg-1000) 6kg 1
4 CASE 1
5 BASE 1
6 FOOT: LEVEL 4
7 BATTERY: COVER 1
8 LUCENT: PLATE 1
9 SHEET: DISPLAY: FRONT 3kg 1
9 SHEET: DISPLAY: FRONT 6kg 1
10 SHEET: DISPLAY: REAR 1
11 SLEEVE 4
12 NAME PLATE: SPEC 3kg 1
12 NAME PLATE: SPEC 6kg 1
13 PUSH RIVET 2
14 PWB PS-005A 1
15 LEVEL UNIT 1
18 SCREW ST 4 x 14 4
19 SCREW M 6 x 25 4
20 WASHER 6 4
21 SPRING WASHER 6 4
22 SCREW M 4 x 12 8
23 SCREW ST 3 x 8 3
24 SCREW M 5 x 16 4
26 SCREW M 4 x 10 5
27 SCREW ST 4 x 10 2
30 CUSHION BATTERY 2
31 SCREW M 4 x 12 1
32 SHEET 2
33 BATTERY HARNESS 1
34 SPRING 1 1
35 SPRING 2 1
36 WASHER 5 4
37 E: RING 3 1
38 PRINTER GND CORD 1
39 FILTER 1
40 PROTECT:SHEET 1
Note: Parts number may change without notice due to product improvement.
