ISHIDA IPC 3kg User Manual

Manual No. 0183B 3/29 IPC Series Service Manual
Chapter 1. Product Overview
1.1 Product Overview
• The IPC Series is a digital scale which can be operated with two batteries.
• The large LCD with 25mm height is provided for the display.
1.2 Standard Specifications
Item Description
Small size Large size
Type name
IPC 3kg IPC 6kg IPC 15kg IPC 30kg
3kg/
1g(0~1.5kg)
2g(1.5kg~3kg)
6kg/
2g(0~3kg)
5g(3~6kg)
15kg/
5g(0~7.5kg)
10g(7.5~15kg)
30kg/
10g(0~15kg)
20g(15~30kg)
Weighing capacity
Dual range Dual range Dual range Dual range
0.001kg 0.002kg 0.005kg 0.01kg
Scale unit
3.000kg/0.001kg 6.000kg/0.002kg 15.000kg/0.005kg 30.00kg/0.01kg
Accuracy 1/3000
Weigh platter size 200mm(L)×230mm(W) 293mm(L)×280mm(W)
Display LCD type 6 digits (7segments) Height : 25mm
Environment condition
Ambient temperature: -5ºC to +40ºC
Relative humidity: 80%RH (Max.), no condensation
Power source
Two D-sized dry batteries or AC adaptor
[ Battery duration ]
Two alkaline D-sized batteries (Approximately 500 hours)
Current consumption Max. 25mA
Auto power off Select: 60 minutes (default), 20 minutes or non Auto power off
Weight (excl. battery) 2.0kg 3.2kg
Option
AC adaptor (Dealer Option)
・Output voltage
- 3.2 to 6.0VDC (current load at 25mA, or at IPC connection)
(caution)
1. Output voltage must not exceed 6.0V even if power supply voltage is at +10%.
2. Output voltage exceeds 3.2V even if power supply voltage is at -15%.
- Generally, AC adaptor output voltage varies with load current.
Confirm output voltage with a 25mA load current (IPC current)
- Output plug configuration/polarity
- Configuration Specification EIAJ RC-5320-2
- Polarity Center Plus
