3.2 Electric Concerns
3.2.1 Block Diagram
Load cell
(4 types depending on
weighing capacity
Batteries
GND connection
Main board PS-005
AC adaptor
(Option)
3.2.2 Board PS-005
CN4
JP1
CN3
CN1
SW5
JP3
CN6
JP2
JP4
GND
(Ｂ)
(Ｇ)
(W)
(R)
JP5
CN2
JP6
CN5
