Manual No. 0183B 17/29 IPC Series Service Manual
IPC 15kg,30kg Single Display Asia Service Parts List
No. Parts Name Weighing Capacity Q'ty
1 PLATTER 1
2 CASE 1
3 LUCENT: PLATE 1
4 SHEET: DISPLAY: FRONT 15kg 1
4 SHEET: DISPLAY: FRONT 30kg 1
5 SCREW ST 3 x 8 3
6 PWB PS-005A 1
7 PRINTER GND CORD 1
8 SCREW ST 4 x 14 4
9 LOAD CELL (CZL-6D-C3-25kg-1000) 15kg 1
9 LOAD CELL (CZL-6D-C3-50kg-1000) 30kg 1
10 SCREW M 4 x 12 2
11 SCREW M 5 x 25 4
12 PLATE: SUPPORT 2
13 PLATE: A: COVER 1
14 SCREW M 4 x 10 9
15 FOOT: LEVEL 4
16 PROTECT: SHEET 1
17 E: RING 3 1
18
SCREW M 4 ｘ12
1
19 BATTERY: COVER 1
20 CUSHION BATTERY 2
21 SPRING 1 1
22 SHEET 1
23 LEVEL UNIT 1
24 SPRING 2 1
25 BASE 1
27 BATTERY HARNESS 1
28 FILTER: CORE 1
29 SCREW M 6 x 25 4
30 WASHER 6 4
31 SPRING WASHER 6 4
32 NAME PLATE: SPEC 15kg 1
32 NAME PLATE: SPEC 30kg 1
33 PUSH RIVET 2
35 SHEET: DISPLAY:REAR 1
Note: Parts number may change without notice due to product improvement.
