Inspection and Installation
• Manually configure the address of the instrument.(Manual)
Set the following parameter. The following information only appear when
Manual is selected.
– IP Addr: This value is the Internet Protocol (IP) address of the instrument.
An IP address is required for all IP and TCP/IP communications with the
instrument. An IP Address consists of 4 decimal numbers separated by
periods. Each decimal number ranges from 0 through 255 with no lead-
ing zeros (for example, 169.254.2.20).
– Sub Net: This value is used to enable the instrument to determine if a cli-
ent IP address is on the same local subnet. The same numbering nota-
tion applies as for the IP Address. When a client IP address is on a
different subnet, all packets must be sent to the Default Gateway.
– Gateway: This value is the IP Address of the default gateway that allows
the instrument to communicate with systems that are not on the local
subnet, as determined by the subnet mask setting. The same numbering
notation applies as for the IP Address. A value of 0.0.0.0 indicates that
no default gateway is defined.
– DNS1: This field enters the primary address of the server. Contact your
LAN administrator for server details. The same numbering notation ap-
plies as for the IP Address. A value of 0.0.0.0 indicates that no default
server is defined.
DNS is an internet service that translates domain names into IP ad-
dresses. It is also needed for the instrument to find and display its host-
name assigned by the network. Normally, DHCP discovers the DNS
address information; you only need to change this if DHCP is unused or
not functional.
– DNS2: This field enters the secondary address of the server. Contact
your LAN administrator for server details. The same numbering notation
applies as for the IP Address. A value of 0.0.0.0 indicates that no default
server is defined.
The operation steps to configure are as follows.
1. Press [Shift]+[Save] (System) to enter into the system menu interface.
2. Use left and right keys or rotate the knob to select Comm and press [Enter]
key to confirm.
3. Use left and right keys or rotate the knob to select LAN and press [Enter]
key to confirm.
4. Use left and right keys or rotate the knob to select Lan Config and press
[Enter] key to confirm.
The first displayed menu
item IP Mode is to configure the instrument
address.
Copyright © Itech Electronic Co., Ltd.
27
