Basic Operation
Pins Name Type Description
5 V-Monitor Analog
out
Voltage monitor signal.
6 I-Monitor Analog
out
Current monitor signal.
7 +10V Analog
out
The +10V reference voltage output by
the power supply can be connected to a
resistance subdivision for analog control.
8 Input1 Analog in The setting for the output voltage/current
value corresponds to Ch1 in the menu.
• CV priority: Specify the value of Vs.
• CC priority: Specify the value of Is.
9 Input2 Analog in The setting for the voltage/current upper
limit corresponds to Ch2 in the menu.
• CV priority: Specify the value of the
current upper limit I+.
• CC priority: Specify the value of the
voltage upper limit Vh.
10 Input3 Analog in The setting for the voltage/current lower
limit corresponds to Ch3 in the menu.
• CV priority: Specify the value of the
current lower limit I-.
• CC priority: Specify the value of the
voltage lower limit Vl.
Analog quantity menu description
When the analog quantity function is optionally equipped, the system menu dis-
plays the analog quantity menu. The analog quantity menu items and parame-
ters are described below:
Ext-Program External analog function menu
On / Off Function switch:
• On: Turns on the external analog function.
In this state, the channel parameters cannot
be set.
Copyright © Itech Electronic Co., Ltd.
160
