Power Supply Function

according to the

selected test

mode.

Charge /

Discharge

Time

Set the charging

or discharging

time according to

the selected test

mode.

Cut Off Voltage Battery test cut-off voltage

Cut Off Current

Battery test cut-off current

Cut Off Capacity Battery test cut-off capacity

This instrument supports battery discharge test in constant current and con-

stant power modes. If the user wants to discharge in constant current mode,

enter the Config menu, select the CC priority, set Vl to 0, set Vh to the rated

voltage value of the instrument, set P- to the rated power value of the instru-

ment, and then set the Battery menu according to the test requirements. If

the user wants to discharge in constant power mode, set P- to the specified

value, and set Discharge V and Discharge I to the rated voltage and current

value of the instrument.

1. Press the composite keys [Shift]+[I-set] (Function) on the front panel to en-

ter the function menu.

2. Use knob to select 2.BATTERY: Off and press [Enter].

The interface is displayed as follows:

FUNCTION BATTERY

Run Edit

3. Press the Left/Right key to select Edit and press [Enter].

4. Press the Left/Right key to select Charge or Discharge and press [Enter].

5. Set the charging voltage (Charge V) or discharging voltage (Discharge V),

charging current (Charge I) or discharging current (Discharge I) and the

other parameters, and then press [Enter] to confirm.

After the parameter setting is completed, the interface returns to the Battery

function main interface and displays as follows:

FUNCTION BATTERY

Run Edit
