Power Supply Function
1
Select the voltage/duration
of 24V starting profile cor-
responding to Level 1.
2
Select the voltage/duration
of 24V starting profile cor-
responding to Level 2.
3
Select the voltage/duration
of 24V starting profile cor-
responding to Level 3.
Load-Dump Load dump curve
Test A
Select centralized load dump
unsuppression
12V
Select the 12V voltage
system
Td Pulse width
Un
Peak voltage
24V
Select the 24V voltage
system
Td Pulse width
Un
Peak voltage
Test B Select centralized load dump
suppression
12V
Select the 12V voltage
system
Td Pulse width
Un
Peak voltage
24V
Select the 24V voltage
system
Td Pulse width
Un
Peak voltage
Us
Clamping voltage
