Power Supply Function
4.6.3.2 Simulate the Waveform to Verify the Anti-interference
Performance of the Automotive Electronics’ Products
To verify the anti-interference performance of the automotive electronics’ prod-
ucts. Output pulse waveform completely meets the International Standard ISO-
16750-2, convenient for quick recall by the user.
ISO16750-2
Simulate the waveform to verify the anti-interference per-
formance of the automotive electronics’ products.
Short-Drop
Automotive short-time voltage drop
waveform
12V
Select the 12V automotive short-
time voltage drop waveform
24V
Select the 24V automotive short-
time voltage drop waveform
Reset-Test
This test is applicable to equipment with re-
set function.
Usmin
The minimum supply voltage Us-
min (Usmin≤80V)
Starting-
Profile
This test verifies the behavior of a DUT dur-
ing and after cranking.
12V
Select the 12V test system.
1
Select the voltage/duration
of 12V starting profile cor-
responding to Level 1.
2
Select the voltage/duration
of 12V starting profile cor-
responding to Level 2.
3
Select the voltage/duration
of 12V starting profile cor-
responding to Level 3.
4
Select the voltage/duration
of 12V starting profile cor-
responding to Level 4.
24V
Select the 24V test system.
