Chapter5 Basic Operation
This chapter introduce the basic operations of IT7320 series AC sourece,including the
following parts:
 Local/remote mode
 Voltage setup
 Frequency setup
 Phase angle setup
 Output on/off operation
 Switch the VFD display items
 Save/recall operation
 Trigger operation
 Menu operation
 Switch output voltage range
 Key lock function
 BNC terminals function
5.1 Local/Remote Mode
Press the local button
to change the AC source from remote to local operation.
After you power on the AC source, it defaults in local mode, all buttons are enabled.
While in remote mode, most buttons are disabled except Shift and Local keys.In addition,
the mode modificaton will not effect the output parameters.
5.2 Voltage Setup
You can set voltage within the range of rated voltage value. When you press
button, the button will be lit. This indicates that you can set voltage. There are three ways to
set output voltage through front panel.
The first way: press
,adjust cursor location through button, pressing
and
will enable you to increase or decrease the setting voltage value.
The second way: press , adjust cursor location through button, adjust
rotary knob
to change the setting voltage value.
The third way: press
button and numeric key(
0
to
9
) to set voltage value
