IT7300 User Manual
User Manual
45
6.3 LAN interface
Press (Shift) + (Menu) on the front panel together to access the menu. Select
LAN in the Communication from System and then configure Gateway, IP, Mask and
SocketPort in the LAN option.
Connect the LAN interface of power supply to the computer with a reticle (crossed).
6.4 GPIB interface
Use a IEEE488 bus to connect GPIB interfaces of power supply and PC. Please ensure
that the screws have been screwed down in order to have a full connection. Then
press
+ (Menu) to enter the system menu to set the address. The address range
of power supply is 0-31.After you set the address, please press
button to confirm,
GPIB address is saved in nonvolatile memory.
