ITech IT7300 Series User Manual

IT7300User Manual
User Manual
32
Trigger source
The power supply supports 2 different trigger modes (Manual and Bus) for LIST test.
When Manual mode is enabled, you can generate an immediate trigger pulse by presing
(Shift)+
Enter
（Trigger）.When bus function is enabled, you can trigger the power
supply by sending a Trigger command to the power supply.The default set is Manual
Communication
There are three types of communication interfaces available:RS-232,USB and LAN.You can
choose any one of them to communicate with a PC.
RS232 interface
Avaiable baudate:4800, 9600, 19200, 38400, 57600, 115.2K
Data bit:8
Parity bit:NONE,ODD,EVEN
Address:0-31
LAN interface
Parameters need to be configured in LAN mode. Gateway, IP address, Mask address and
socket port.
Before communicating with the principal computer, choose the communication port and
perform associated configuration to ensure that communication configuration of the power
accords with that of the principal computer.
2. Config menu
Volt-Min:
Voltage lower limit setting
Volt-Max:
Voltage upper limit setting
Freq-Min:
Frequency lower limit setting
Freq-Max:
Frequency upper limit setting
Irms-Protect: Current RMS upper limit setting
Ipeak-Protect: Peak Current upper limit setting
3. Instrument information
Step Operation VFD display
1
Press
(Shift)+ （Menu）to enter menu
operation
MENU
System Config Info
2
press right direction key to select INFO,press
Enter
PRODUCT INFO:
IT7321 Ver:0.06~0.06
