ITech IT7300 Series User Manual

IT7300User Manual
User Manual
30
RS232(Def) RS232
Select RS232
interface
GPIB Address
Available range from
0-31
4800,8,N,1
9600,8,N,1
19200,8,N,1
38400,8,N,1
57600,8,N,1
Set Baud rate,data
bit,odd-even
check,stop bit and
address
USB Select USB interface
LAN LAN Select LAN interface
Gateway=192.168.0.1
IP=192.168.0.125
Mask=255.255.255.0
Socket Port=30000
Set gateway, IP
address, mask
address and port.
Config
CONFIG
Config menu
Volt-Min
Voltage lower limit
Volt-Min=0.0V Set Min. voltage
Volt-Max
Voltage upper limit
Volt-Max=300.0V Set Max, voltage
Freq-Min
Frequency lower limit
Freq-Min=45.0Hz
Freq-Max
Frequency upper limit
Freq-Max=500.0Hz Set frequency upper limit
Irms-Protect
Current RMS protect point
Irms-Protect=12.000A Set current RMS protect point
Delay
Irms protection will be
triggered in 1s
Immediate
Protection will be
triggered immediately.
BNC-Set
BNC PORT SETUP
I-Trigger Input interface for external trigger
I-Ri Input interface for on/off control
O-Sync
Output interface for AC phase synchronization
signal
O-On Output interface for on/off state interface
Ipeak-Prote
ct
Current peak protect point
Ipeak-Protect=12.000A Set Current peak protect point
Dimmer
DIMMER Phase dimmer
LeadingEdge
LeadingEdge Phase dimmer function
TrailingEdge TrailingEdge Phase dimmer function
Off Disable Phase dimmer function
List-Set
LIST START MODE
LIST mode is used to simulate the power line
disturbance.
On/off Enable List function
Trigger
Press Shift+Enter(Trigger)to give a trigger signal
3ø-Setup
A-Phase/ B-Phase /
C-Phase
Configure phase line of each unit.(IT7321 do
not support this function.)
