SYSTEM BUS：
User need to connect three units together via a straight network cable.
Please see figure above.
3-phase configuration:
(1)Configure phase line of each unit.For example,specify the #1-IT7324 to A
phase,#2-IT7324 is set to B phase and #3-IT7324 is set to C phase.
(2)The phase-A unit will search B-phase and C-phase units automatically.
(3)Press
(Shift)+ （Menu）to enter the menu operation,press right-key to select
CONFIG,then press
Enter
button to confirm.
(4)Press right key to select 3ø-Setup,then press enter to configure the A,B,C phase.
Two parameters need to be set from the menu to enable this function:
A-Phase/ B-Phase / C-Phase Configure the phase line of each unit
Disable/Enable Turn on or turn off 3-phase function
OFF
3ø-Setup
A-Phase Disable
