Remote Control
Copyright © Itech Electronic Co., Ltd. 8
The device is RL1 capable.
The device is DT1 capable.
When communicating with USB interface, the first you should set
communication interface as USB in the panel menu. The detailed steps are as
follows:
1. Press (Shift)+ to enter the menu.
2. Press and select SYST SET, then press , the .”P-MEM KEEP”
will display on the panel. At the same time, press and select COMM
RS232, then press .
3. Press and select USB, then press to confirm.
4. Press to exit the menu.
Note
When communicating with USB interface, only SCPI format communication protocol is
supported.
1.6.2 GPIB Interface
First connect GPIB port of load to GPIB card of PC with IEEE488 BUS. They
must be sufficient contact and tighten the screws. And then set address. The
address can be set from 0 to 31. Press [Menu] key to enter system menu,
press [COMM CONFIG] to find Communication interface. Select GPIB, and
then set the GPIB address, press [Enter] to confirm. The electronic load
operates from a GPIB address set from the front panel. The GPIB address is
stored in non-volatile memory.
1.6.3 LAN Interface
Press [Menu] on the front panel together to access the menu. Select [COMM
CONFIG] to enter communication configuration page. Select LAN by pressing
arrow keys and then configure Gateway, IP, Mask and Socket Port in the LAN
option. Use a cross network cable through LAN interface to connect PC.
