ITRON OpenWay Riva - Extending the Water Pit Module Cable; Pit Module Encoder-Type Meter Register Connections

Caution: Do not program configuration changes to the OpenWay Riva Water
module until it is connected to the water meter register.
• The FC300SR or Itron Mobile Radio are the only devices that support
programming for the OpenWay Riva Water module.
• Keep a minimum of 12 inches between the OpenWay Riva pit water module and
programming device while programming configuration changes are completed.
• Do not place the programming device antenna directly on the pit module.
Extending the water pit module cable
Order the 25-foot inline connector extension cable assembly (CFG-0151-404) to extend the
cable of the pit module.
Pit module encoder-type meter register connections
Pit module connections are made by the meter manufacturer for encoder-type registers.
This information describes those connections.
Caution:
Itron recommends OpenWay Riva pit module connections be completed
using the inline connector. In rare instances, if a spliced connection is made, the
Itron splice kit must be used (Itron part number OEM-0034-002). For more
information, see Completing Gel-cap Connections Using the Itron Splice Kit on page
36.
Pit module wire color
Red
(data)
Black
(power/clock)
White
(ground)
Register manufacturer Register screw terminal
Badger
ADE
E Series
HR E LCD
HR E Mechanical
Green Red Black
Badger M5000 Mag Meter Green Terminal: Out 4+ Red Terminal: Input +
Black Terminal: Input - and
Out 4-
Diehl Hydrus Green Red Black
Elster AMCO
InV
ision
Scancoder
AquaMaster
AquaMaster III
Red Green Black
Initializing, Connecting, and Programming the Pit Module
OpenWay Riva Water Pit Module Installation Guide TDC-1743-004 11
Proprietary and Confidential
