Warning:
While Itron modules are designed to withstand a drop, dropping the module may
damage the device and void the warranty.
Pit module positioning other than upright will negatively affect radio performance.
Internal circuit card components are sensitive to electrostatic discharge. Be careful
not to touch any part of the meter body, register housing, or Riva module prior to
discharging any static buildup on your person. To discharge yourself, touch a
grounded metal object such as the metal water pipe or an earth-grounded metal
structure.
Pit module mounting accessories
Accessory Part number
Remote antenna kit (required for rod and wall
mount installations)
CFG-0900-003
Riva water module rod mount adapter CFG-1601-002
Fiberglass mounting rod. (Minimum order quantity is 100.)
12" OEM-1006-001
18" OEM-1006-002
36" OEM-1006-003
Riva water module pit lid mounting kit CFG-1601-001
Cable armor (see Using the Itron Cable Armor on page 32
for field retrofit installation instructions)
5 foot cable thin-insulation (with protective cap
and cable armor)
CFG-0151-006SS
5 foot cable thick-insulation (with protective cap
and cable armor)
CFG-0151-010SS
5 foot cable armor for field retrofit FAB-1302-001
Pit module universal environmental cap MSC-0019-011
Itron security seal MSC-0018-001
Caution: Shield unconnected pit module connectors on field installed modules with
protective environmental caps. Do not leave an exposed connector in the field.
Environmental caps employ multiple seals to increase connector life.
Pit modules with integral connectors
Prior to connecting inline connectors to the pit module connectors, remove the
environmental cap. If pit modules with integral connectors (ERW-1601-001) and the
registers are not installed at the same time, secure the protective environmental connector
cap on the pit module connector using an Itron security seal (Itron part number
MSC-0018-001). Cable ties are not shipped with the pit module, but can be ordered from
Itron. Use the protective cap (on the pit module side) in the field for up to one year.
Installing the OpenWay Riva Water Pit Module
OpenWay Riva Water Pit Module Installation Guide TDC-1743-004 15
