4. Verify that the clip locks into place and the retainer clip collar is hand-tightened against
the pit lid.
Caution:
Carefully align the pit module through lid assembly. If the assembly is
improperly aligned, the pit lid may not close.
Pit lid mounting installation is complete.
Rod mount installation
Important:
Rod mount installation requires the remote antenna and rod mount adapter. For
more information, see Pit module mounting accessories on page 15
OpenWay Riva Water Pit Modules can mount below the pit lid on a customer-supplied 1/2-
inch diameter rod. A mounting rod is available from Itron. For more information, see Pit
module mounting accessories on page 15 or visit www.itron.com and reference the Water
Products Ordering Guide (PUB-0063-001).
Installing the OpenWay Riva Water Pit Module
OpenWay Riva Water Pit Module Installation Guide TDC-1743-004 18
