Pit module pulser-type register connections
Pit module connections are made by the meter manufacturer for pulser-type registers. This
information describes those connections.
Caution: Itron recommends OpenWay Riva pit module connections be completed
using the inline connector. In rare instances, if a spliced connection is made, the
Itron splice kit must be used (Itron part number OEM-0034-002). For more
information, see Completing Gel-cap Connections Using the Itron Splice Kit on page
36.
Module wire color
Red Black White
Register manufacturer Register screw color designator
Badger RTR (3-wire) Red Black Green
Badger RTR (2-wire) Red Black No connection
Badger M5000 Mag Meter Red terminal: Out 1+ Black terminal: Out 1- White terminal: Out 1+
Cadillac Meter CMAG/EMAG
Magnetic Flow
DO1/DO2 COM DO1/DO2
Elster Digital Black Green Red
Elster V100T Black Red Blue
Itron (Actaris)
Flostar (2-wire)
Cyble Sensor
Either wire
Remaining wire must be connected to both ERT module
wires
Krohne IFC Term B Term H Term B
RG3 Tomahawk Green Black Green
Sensus PMM Red Black Bare
Verifying pit module operation
Use one of the following handheld computers to verify consumption:
• FC300SR handheld computer
• Itron Mobile Radio connected to a user-supplied computer or Bluetooth device
Caution:
Verifying the OpenWay Riva Water Pit Module operation requires an
FC300SR handheld computer or Itron Mobile Radio running FDM v4.0 or higher.
Legacy Itron handheld programming devices cannot read the pit modules.
• Each handheld radio requires special setup and configuration parameters to
successfully read and program the pit module. Refer to the respective meter
reading application for specific instructions.
• When comparing the actual register value to that reported by the pit module,
please keep in mind the water module's consumption value is updated once an
hour when it is in Run Mode.
