Caution: Do not force the connector ends together. While you hold the disconnect
valve's connector, engage the pit module's connector by rotating the locking ring
until both connectors are securely connected. Twist only the connector locking
ring, not the body of the connector. Twisting the connector body could damage
the pit module and disconnect valve's connector pins.
Install an Itron security seal through the aligned security holes. For more information, see
Attaching a security seal.
Optional through-the-lid remote antenna installation
Important: The remote antenna and rod mount adapter are required for all rod and wall
mount installations. For more information, see Pit module mounting accessories on page 15.
This section provides antenna mounting and connection instructions for modules installed
through a pit lid. This device has been designed and approved per FCC and ISED rules, to
operate with the antennas listed below. Antennas not included in this list are strictly
prohibited for use with this device. The required antenna impedance is 50 ohms. To reduce
potential radio interference to other users, the antenna type and its gain should be chosen
so that the equivalent isotropically radiated power (e.i.r.p.) is not more than that permitted
for successful communication. The optional 900 MHz remote mount antenna provides
increased RF range coverage for the listed mobile applications where the meters are
located deep in pit boxes.
Specification
Part number CFG-0900-003
Gain 2 dBi
Horizontal beamwidth Omni-directional
Impedance 50 ohms
Termination Proprietary
Innovation, Science and Economic Development Canada (ISED) Conformity
The radio transmitter (IC:864D-RIVAWA) has
been approved by Innovation, Science and
Economic Development Canada (ISED) to
operate with the antenna types listed above with
the maximum permissible gain and required
antenna impedance for each antenna type
indicated. Antenna types not included in this list,
having a gain greater than the maximum gain
indicated for that type, are strictly prohibited for
use with this device.
Le présent émetteur radio (IC: 864D-RIVAWA) a
été approuvé par Industrie Canada pour
fonctionner avec les types d'antenne énumérés
ci-dessous et ayant un gain admissible maximal
et l'impédance requise pour chaque type
d'antenne. Les types d'antenne non inclus dans
cette liste, ou dont le gain est supérieur au gain
maximal indiqué, sont strictement interdits pour
l'exploitation de l'émetteur.
Installing the OpenWay Riva Water Pit Module
OpenWay Riva Water Pit Module Installation Guide TDC-1743-004 28
