COLLEGAMENTI ELETTRICI
ELECTRICAL CONNECTIONS
RACCORDEMENTS ÉLECTRIQUES
ELEKTROANSCHLÜSSE
CONEXIONES ELÉCTRICAS
17

1
3 / 4
18 / 30
7
11 / 12 / 13 /
14 / 15 / 16
17
8
10
9
17
5 / 6
1
Alimentazione (O.E.) + 24 V (O.E.) Power supply + 24 V
3 / 4
Elerovenlatore evaporatore (O.E.) - Collegamen (O.E.) Evaporator electric fan - Connecons
5 / 6
Gruppo compressore elerico - separatore d’olio / Pressostato lineare Electric compressor - oil separator group / Linear pressure sensor
7
Centralina eleronica di controllo (ECU) Electronic control unit (ECU)
8
Pannello comandi Control panel
9
Sonda di temperatura aria interna Internal air temperature probe
10
Collegamento + chiave + key connecon
11 / 12 / 13
/ 14 / 15
/ 16
Gruppo relais e fusibili Relays and fuses group
17
Elerovenlatore condensatore Condenser electric fan
18 / 30
Collegamento - Tagliare il cablaggio (O.E.) dell’elerovenlatore evaporatore e interporre il cablaggio fornito. Connecon - Cut the (O.E.) wiring of the evaporator electric fan and interpose the supplied wiring.
