Iveco STRALIS E6 - Positioning of Electric and Electronic Components - Connections; Control Panel Positioning

35/56
IT EN FR DE ES
COOLANT FILLING
Connect the "lling staon", create a vacuum in the circuit and pre-ll
with coolant, then look for any leaks.
If there are no leaks, reconnect the baery, start the engine and
completely ll with coolant.
The quanty and type of coolant to use in the circuit are those of
the vehicle's O.E. system, indicated on the idenfying plate.
 (of the same type as
that used in the O.E. system, also indicated on the idenfying plate).
Disconnect the "lling staon".
CONTROL PANEL POSITIONING
The  is the interface between the user and the
system so it is important to posion it somewhere that is comfortable
and easy to reach.
To allow maximum exibility in the choice of posion, we have created
an alternave fastening to the tradional mechanical fastening, to
allow posioning on various types of surface.
The special double-sided scky tape supplies allows easy, quick and
durable fastening. Cut it to size (if necessary), remove the protecve
lm and glue it to the control panel; then remove the other lm and
fasten everything to the chosen surface .
POSITIONING OF ELECTRIC AND ELECTRONIC
COMPONENTS - CONNECTIONS


     


Make the electrical connecons as per the wiring diagram.
The  can
be placed in the central tunnel area, below the dashboard .
The can be
placed near the relay and fuses plate (O.E.) located on the dashboard
(passenger side) .
The  can be
made in the area behind the relay and fuses plate (O.E.) .
The 
must be placed near the air intake chamber in such a way that it detects
the temperature inside the cockpit .
The connecon to the power supply can be made at the point indicated
in .
CONNECTION (18  TO THE O.E. ELECTRIC FAN
OF THE EVAPORATOR 
Interrupt the connecng wires between the electronic speed regulator
(3  and fan (4 , bu
with two-way adapters and terminals supplied and interpose the wiring
supplied.
The passage of the wirings between outside and inside the cabin can be
made at the point indicated in .
For the  see the next
secon.
 
1 Power supply + 24 V (O.E.)
3 Electronic speed regulator (O.E.)
4 Evaporator electric fan (O.E.)
5 Electric compressor
6 Linear pressure sensor
7 Electronic control unit (ECU)
8 Control panel
9 Internal air temperature probe
10 + key connection
11 / 12 /
13 / 14 /
15
Exchange relay
16 20 A fuse
17 Condenser electric fans
18 Connection to evaporator electric fan (O.E.)
19 Earth connection
20 80 A fuse
30 Connecng to bridle for evaporator electric wiring (O.E.)
31 -
ELECTRICAL WIRING DIAGRAM KEY
If you want to hide the passage of the wiring of the control panel,
it is possible to make a hole in the wall  or the base 
- D) on which the panel is going to rest and insert the wire. The four-
way adapter supplied, must be connected to the wiring aer inserng
the wire through the hole .
If necessary, to avoid interference with the wiring and facilitate
the resng of the control panel on the wall or on the base, it is possible
to remove the part indicated in .
Bu the electric connecons between the various components and
fasten the wire bundles in place using appropriate clips.
