Iveco STRALIS E6 - Supplied Components

33/56
IT EN FR DE ES
  
Compressor / oil separator group A 1
Le support bracket for the compressor / oil separator
group
B 1
Right support bracket for the compressor / oil separator
group
C 1
Oil for electric compressor (0,25 l) D 1
Hex. head screw M14x30 AA 4
Flat washer Ø14xØ28 BB 8
Elasc conical washer Ø14xØ27 CC 4
Nut M14 DD 4
Spacer Ø10xØ28x15 EE 12
Hex. head screw M10x40 FF 4
Hex. head screw M10x80 GG 4
Flat washer Ø10xØ20x2 HH 8
Self-locking nut M10 II 4
Sloed bracket for supporng the electric fan E 4
Bracket to fasten the sloed bracket to the condenser F 4
Electric fan G 2
Flat washer Ø5xØ15 JJ 16
Self-locking nut M5 KK 16
G8 hose H 4 m
G10 hose I 4 m
Insulang hose for G10 hose J 4 m
90° ng for G8 hose K 1
90° ng for G10 hose L 1
Clip for fastening ng to G8 hose M 1
Clip for fastening ng to G10 hose N 1
Supporng hoses bracket O 1
Supporng hoses clamp P 1
Hex. head screw M8x30 LL 1
Flat washer Ø8xØ17 MM 1
Self-locking nut M8 NN 1
Hex. head screw M6x20 OO 1
Flat washer Ø6xØ18 PP 1
Self-locking nut M6 QQ 1
SUPPLIED COMPONENTS
  
Primary wiring Q 1
Wiring for connecon to O.E. electric fan evaporator R 1
Wiring for connection to battery S 1
Internal air temperature probe T 1
Control panel U 1
Double-sided scky tape to fasten the control panel V 1
Electronic control unit (ECU) W 1
Remote control X 1
Label for remote control Y 1
1.5V baery Z 2
Installation manual AB 1
User manual AC 1
Special sucon ng AD 1
Special delivery ng AE 1
O Ring Ø10.8 AG 2
O Ring OR Ø13.5 AH 2
Clip for fastening ng to G8 hose AI 1
Clip for fastening ng to G10 hose AJ 1
Hex. head screw M8x50 RR 1
Hex. head screw M8x60 SS 1
Wavy washer Ø8 TT 2
