Iveco VECTOR Series User Manual

SECTION 3 - INDUSTRIAL APPLICATION
51
VECTOR 8 ENGINES
Print P2D32V001E Base - April 2006
Pinout of engine side connector XJ2
Pin
Function Cable code
1 Potential +5V su pplying atmospheric pressure sensor 0905
2 Potential +5V supplying rail fuel pressure sensor 1004
3 Reference potential 0V for the rail fuel pressure sensor 1005
4 Not used —
5 Not used —
6 Not used —
7 Not used —
8 Not used —
9 Not used —
10 Not used —
11 Not used —
12 Not used —
13 Not used —
14 Indicator signal of atmospheric pressure 0907
15 Not used —
16 Not used —
17 Not used —
18 Reference potential 0V fo r th e atmospheric pressure sensor 0906
19 Not used —
20 Cylinder 2 injector (pin 2) 0915
21 Cylinder 4 injector (pin 2) 0918
22 Not used —
23 Not used —
24 Indicatorsignalofrailfuelpressure 1006
25 Indicator signal of engine oil pressure 0910
26 Not used —
27 Not used —
28 Cylinder 6 injector (pin 2) 0921
29 Cylinder 8 injector (pin 2) 1013
30 Not used —
31 Not used —
32 Indicator signal of engine oil temperature 0911
33 Indicator signal of engine coolant temperature 1002
34 Indicator signal of fuel temperature 1003
35 Indicator signal of turbo—blower air temperature 0912
36 Common to pins 1 of cylinder 1 an d 2 injectors 0913
37 Common to pins 1 of cylinder 3 an d 4 injectors 0916
38 Common to pins 1 of cylinder 5 an d 6 injectors 0919
39 Common to pins 1 of cylinder 7 an d 8 injectors 1011
40 Indicator signal of turbine air outlet pressure 1001
41 Potential + 5V supplying turbine air outlet and engin e oil pressure sensors 0908
42 Reference potential 0V for the sensors on the engine 0909
43 Not used —
44 Cylinder 1 injector (pin 2) 0914
45 Cylinder 3 injector (pin 2) 0917
46 Cylinder 5 injector (pin 2) 0920
47 Cylinder 7 injector (pin 2) 1012
48 Positive of the engine speed sensor 1009
49 Negative of the engine speed sensor 1010
50 Not used —
