Figure 67
LUBRICATION
The engine is lubricated by a gear pump driven by the
crankshaft.
There is a safety valve located on the oil filter moun ting wh ich
starts opening at 3.4 ± 0.3 bar.
Lubricating pressure with oil at 110 °C:
- max pressure up to 6.5 bar
- min pressure 4.0 bar
- Remove the covers (1) and (2) by unscrewing the screws
(3).
- Change the filtering parts (4) an d the gaskets (5).
- Carefully clean the blow—by filter body (6) and th e
covers.
The o il vapours that form in side th e engine during o peration
are directed into a condenser (blow-by filter) where some
of them are condensed and recirculated again and some of
them are directed via two pipes to the intake.
The oil vapour condenser needs a periodical overhaul.
engine oil is a pollutant. Protect your skin suitably
against contac t with engin e oil.
