Iveco VECTOR Series

VARIANT FOR APPLICATIONS WITH BRAKE AIR COMPRESSOR
Figure 8
103509
10
SECTION 1 - GENERAL SPECIFICATIONS
VECTOR 8 ENGINES
Base - April 2006 Print P2D32V001E
Rif. Description
1 Circulation pump
2 Engine lubrication water/oil heat exchanger
3 Airsystemcompressor(forDRAGONapplications)
