Iveco VECTOR Series User Manual

SECTION 4 - OVERHAUL AND TECHNICAL SPECIFICATIONS
1
VECTOR 8 ENGINES
Print P2D32V001E Base - April 2006
SECTION 4
Overhaul and technical specifications
Page
GENERAL SPECIFICATIONS 3...............
ASSEMBLY CLEARANCE DATA 4............
ENGINE OVERHAUL 10.....................
- Dismantling the engine at the bench 10........
REPAIR OPERATIONS
CYLINDER UNIT 11......................
- Checks and measurements 11...............
- Replacing Cylinder Liners 12................
TIMING SYSTEM 14........................
- Camshaft 14.............................
- Checking cam lift and
pin alignment 14..........................
- Replacing the camshaft
idle gear 14..............................
- Changing the bushings 16...................
- Changing the tappets 16...................
- Fitting tappets and camshaft 16..............
OUTPUT SHAFT 16........................
- Measuring journals and crankpins 16..........
- Checking main journal alignment 18...........
- Crankshaft balancing instructions 19..........
- Replacing water pump drive gear 19..........
- Changing the oil pump and
timing system gear 20......................
- Fitting the main bearings 20.................
- Finding journal clearance 21.................
- Tightening sequence 21....................
- Checking crankshaft thrust clearance 22.......
- Camshaft timing 23.......................
