SUPERCHARGING
The exhaust fumes are directed to the turbocharger (1) which rotates the section which draws in the air from the filters and
compresses i t (with a consequent increase in temperature).
The hot compressed air is directed to the inside of the heat exchanger (air/air intercooler) in which it is cooled and sent to the
intake manifolds and to the inlet valves.
Figure 11
103512
FROM THE AIR/AIR
HEAT EXCHANGER
TO THE AIR/AIR
HEAT EXCHANGER
SECTION 1 - GENERAL SPECIFICATIONS 13
VECTOR 8 ENGINES
Print P2D32V001E Base - April 2006
