SECTION 4 - OVERHAUL AND TECHNICAL SPECIFICATIONS
VECTOR 8 ENGINES
Base - April 2006 Print P2D32V001E
Page
PISTON ROD ASSEMBLY 28.................
- Pistons 28...............................
- Measuring the piston diameter 28............
- Gudgeon pins 28..........................
- Conditions for c orrect mating of gudgeon
pin and piston 29.........................
- Piston rings 29............................
- Connecting rods 30.......................
- Check of c onnectin g rod alignment 31.........
- Fitting the c onnecting rod—piston assembly 31...
- Connecting rod—piston mating 31............
- Fitting the piston rings 31...................
- Check of rod/piston alignment 32.............
- Fitting the rod—piston assemblies
into the cylinder liners 32...................
- Measuring the mounting clearance of big end pins 33
- Fitting the connecting rod caps 33............
- Check of piston protrusion 33...............
CYLINDER HEAD 34........................
- Hydraulic leak test 34......................
- Dismantling valves 34......................
- Checking the cylinder head support surface 34..
VALVE 34.................................
- Removing carbon deposits, and checking the valves 34
- Refacing t he valves 35......................
- Checking valve centering 35.................
- Checking clearance between valve stem 35.....
VALVE GUIDES 35..........................
- Replacing the valve guides 36................
- Reaming t he valve guides 36.................
- Replacing and regrinding the valve seats 36.....
Page
REPLACING THE INJECTOR—HOLDER CASES 37
- Fitting the valves 38.......................
- Installing the c y linder h ead 38................
TIGHTENING TORQUE 39..................
