Iveco VECTOR Series User Manual

2
SECTION 3 - INDUSTRIAL APPLICATION
VECTOR 8 ENGINES
Base - April 2006 Print P2D32V001E
Page
SECOND PART -
ELECTRICAL EQUIPMENT 43..............
LOCATION OF COMPONENTS ON THE ENGINE 45.
- Circuit diagram of engine cable 46............
- Engine components 47.....................
- ADEM III engine control unit 50..............
- Electronic control of the engine control unit 53..
THIRD PART - DIAGNOSTICS 55............
TROUBLESHOOTING 57....................
- General information 57.....................
TROUBLESHOOTING WITH TOOL 99368550 58
- Connection procedures 58..................
- Diagnosis procedures for Vector 8V engines 59..
- Diagnosis Environment 60..................
ENGINE PARAMETER READING 63...........
READING PARAMETER FOR SAVE CODE 64....
EVENTS TABLE 65..........................
FAULTS TABLE 67.........................
ILC SIMULATOR 99368543 TOOL 70..........
FOURTH PART -
PLANNED MAI NTENANCE 77.............
VECTOR 8 DRAGON FVAE2884A*B200
MAINTENANCE PLAN 79.................
VECTOR 8 GENSET FVAE2885X* A100
MAINTENANCE PLAN 81.................
DESCRIPTION OF PREVENTIVE AND
ROUTINE MAINTENANCE WORK 83.......
CHECKING/REFILLING ENGINE OIL FILTERS 84.
CHANGING ENGINE OIL FILTERS 84..........
CHANGING THE ENGINE OIL 86.............
CHANGING FUEL PREFILTER AND
WATER SEPARATOR FILTER 87............
ADJUSTING ROCKER ARM ASSEMBLY 88......
CHANGING FUEL FILTERS 91................
Page
CHANGING AN INJECTOR 93...............
CHANGING BLOW-BY FILTER 95.............
CHANGING PRIMARY SYSTEM PUMP 96.......
- Removal 96..............................
- Fitting 97................................
REMOVING/REFITTING STARTER MOTOR 98...
- Removal 98..............................
- Fitting 98................................
