Technical Data
136
12 Technical Data
The following technical data refer exclusively to the PrograMill One milling machine.
For information on the technical data of the accessories or other components of
PrograMill One, please refer to the respective operating instructions.
12.1 Classifications
12.2 Measurements, weight
Characteristics Value
Test standards • IEC 61010-1:2010
• EN 61010-1:2010
• UL 61010-1:2012-05
• CAN/CSA-C22.2 No. 61010-1:2012-05
Radio protection / Electromagnetic
compatibility
EMV certified
Noise level (Measuring conditions): 70 dB(A)
All other action movements (tool change,
axis movement, etc.): 70 dB (in 1 m distance)
Measuring conditions:
• Tools (standing time expired)
• Measuring distance to sound source 1m
• Measurement according to ISO 3746,
accuracy class 3
Characteristics Value
Height 479 mm
Diameter 340 mm
Weight 36.5 kg (80.5 lbs)
