Transportation and Assembly
32
4.3 Unpacking the unit
WARNING! Risk of injury due to heavy lifting or the device falling down.
Injuries to the back due to overloading.
Crushing of extremities.
Damage to the device.
Remove the device from the inner box with at least two people.
Always hold the device on the handhold and the device floor.
Remove the fabric cover with handholds once the device is positioned on its definitive
working surface.
Position the device carefully.
1. Cut the transport bands with scissors (1).
2. Fold in the handholds of the outer
cardboard box.
The handhold will be unlocked.
3. Remove the handhold of the outer
cardboard box (2).
4. Lift the outer cardboard box.
For this purpose, please observe the detailed
information on the outer cardboard box.
