Design and Function
23
No. Description Function
1 OSD ring Display device status
2 Milling chamber Processing blocks / workpieces
3 Material and tool changer (under the
secure housing cover)
Cartridge for blocks and tools for the
pending milling jobs:
• Max. 5 blocks with the adapted
Ivoclar Vivadent standard holder or
"ESD pin B axis for One”
• Max. 8 milling, grinding and cleaning
tools. Make sure that the cleaning tool
is inserted into the tool holder slot
marked with “II”. The second position
must be left empty.
4 Tank with integrated filter • Intake coolant fluid
• Filter for the used coolant fluid before
it is reused in the milling chamber
5 Maintenance access with loading aid Loading the material and tool changer
6Lever
7 Opening to the milling chamber Access to the milling chamber
