Jackson ECOLAB ES-2000 - SDI Option (ES-2000 HHV)

ES-2000 & ES-4000 Series Installation/Operation Manual 7610-011-35-10
Issued: 10-29-2007 Revised: N/A
SECTION 6: PARTS SECTION
ES-2000HHV SDI OPTION
76
Hood Weldment for
ES-20000HHV
Interlock Frame
Ecolab No.: N/A
Mfg. No.: 05700-002-92-30
Interlock Solenoid Link
Ecolab No.: N/A
Mfg. No.: 05700-002-92-36
Interlock Rod Sleeve
2 per assembly
Ecolab No.: N/A
Mfg. No.: 05700-002-92-40
Solenoid, 110 Volt
Ecolab No.: 83999078
Mfg. No.: 04810-200-11-00
Interlock Rod Link
Ecolab No.: N/A
Mfg. No.: 05700-002-92-35
Bearing, Nyliner Flanged
Ecolab No.: N/A
Mfg. No.: 3120-002-71-66
Interlock Rod
Ecolab No.: N/A
Mfg. No.: 05700-002-92-34
Bearing, Sleeve
2 per assembly
Ecolab No.: N/A
Mfg. No.: 05700-002-71-68
Interlock Pin
Ecolab No.: N/A
Mfg. No.: 05700-002-92-37
Interlock Pin Plate
Ecolab No.: N/A
Mfg. No.: 05700-002-92-38
