www.janitza.com UMG 103-CBM
37
Slave
Fig. Bus structure
Slave
Slave Slave
Repeater
Slave
Slave Slave
Master
Power supply necessary
Bus terminator on
T
T
T
T
T
Master - e.g. UMG 604-PRO
Slave - e.g. UMG 103-CBM
