10.13 Recording the measured values
The standard setting of the measurement device
includes 2 recording profiles that you can adapt or
expand in the GridVis
®
software.
· The smallest time base for recordings is 1 min-
ute.
· A maximum of 4 recordings with 29 measured
values each is possible.
If minimum and maximum values are defined as
well, the number is reduced to 19 or 14 values,
respectively.
· Within the recording configuration, measured
values are defined via a time base according to
the types Average value, Sample, Maximum or
Minimum.
· Average value type: Arithmetic mean value of
the measured values over a defined period of
time.
· Maximum and Minimum type: Maximum or
minimum values of a specified time period.
· Sample type: Measured value at the end of
the specified time period.
INFORMATION
A recording of work values is only possible with the
type Sample!
Recording 1:
The following measured values are recorded with
a time base of 15 minutes:
• Effective voltage L1
• Effective voltage L2
• Effective voltage L3
• Effective current L1
• Effective current L2
• Effective current L3
• Effective current, sum L1..L3
• Active power L1
• Active power L2
• Active power L3
• Active power, sum L1..L3
• Apparent power L1
• Apparent power L2
• Apparent power L3
• Apparent power, sum L1..L3
• cos phi(math.) L1
• cos phi(math.) L2
• cos phi(math.) L3
• cos phi(math.) Sum L1..L3
• Reactive power fundamental oscillation L1
• Reactive power fundamental oscillation L2
• Reactive power fundamental oscillation L3
• Reactive power fundamental oscillation sum
L1..L3
Recording 2:
On a time base of 1 hour, the measurement device
records the following measured values:
• Applied active energy L1
• Applied active energy L2
• Applied active energy L3
• Applied active energy, sum L1..L3
• Inductive reactive energy L1
• Inductive reactive energy L2
• Inductive reactive energy L3
• Inductive reactive energy, sum L1..L3
